Ferrite (Ceramic) Shallow Pot Magnets with Threaded Hole
Ideal for light lifting, holding, securing and clamping applications
- 120° maximum operating temperature
- Excellent resistance to corrosion
- Mild steel pot with red painted body
- Female thread
Overview - Ferrite (Ceramic) Shallow Pot Magnets with Threaded Hole
Internal Threaded Stud Pot Magnet / Female Threaded Stud Pot Magnet
Ferrite Shallow Pot Magnets with Threaded Hole are permanent magnetic assemblies engineered for secure magnetic holding and threaded mounting in workshop, industrial, commercial, retail, and domestic applications. These magnets combine a ceramic ferrite magnet core with a steel pot housing, concentrating the magnetic field at the contact surface to deliver reliable magnetic attraction in a compact, low-profile design.
The threaded hole in the pot enables secure attachment using bolts or screws, allowing easy integration into fixtures, panels, machinery frames, or engineered assemblies where both magnetic performance and mechanical fixation are required. The shallow pot format ensures efficient magnetic flux direction while minimising overall height, making these magnets suitable for space-restricted or flush-mount installations.
Ferrite magnet material is known for its corrosion resistance, thermal stability, and long-term magnetic reliability, making these shallow pot magnets a durable choice for environments where moisture, temperature fluctuation, or frequent handling might impact other magnet types.
Typical Applications
Ferrite Shallow Pot Magnets with Threaded Hole are commonly used for:
Magnetic holding and attachment in fabrication, assembly, and workshop environments
Mounting fixtures, panels, and covers using threaded fixings
Tool and equipment organisation on steel frames and workstations
Display and panel mounting in retail and exhibition setups
DIY and hobby magnetic projects requiring secure magnetic fixings
Their combination of dependable magnetic performance and threaded mounting capability makes them suitable for a wide range of professional and general-purpose tasks.
Why Choose Ferrite Shallow Pot Magnets with Threaded Hole
Ferrite shallow pot magnets with threaded hole balance consistent magnetic holding force, mechanical flexibility, and rugged durability in a compact assembly. The steel pot enhances magnetic flux direction while protecting the magnet core from impact and wear, and the threaded mounting option allows secure integration into engineered solutions. These magnets are a practical choice for users who need dependable permanent magnets with secure threaded attachment across many everyday and professional applications.
Key Benefits
Reliable magnetic hold – consistent attraction across ferrous surfaces
Threaded hole – secure mechanical fixing with bolts or screws
Shallow pot design – low profile and space-efficient magnet
Corrosion-resistant ferrite material – durable for workshop and general use
Versatile uses – mounting, fixturing, display, workshop, and DIY applications
High tempreture - Can be used at temperatures up to +120 degrees C and is suitable for almost any application.
Model Variations
| Product Number | Diameter (mm) | Thickness (mm) | Overall Height (mm) | Thread | Weight (mm) | Pull Force (kg) | Units per pack |
|---|---|---|---|---|---|---|---|
| E860 | 10 | 4.5 | 11 | M3 | 3 | 0.4 | 20 |
| E861 | 13 | 4.5 | 11.5 | M3 | 5 | 1.0 | 20 |
| E862 | 16 | 4.5 | 11.5 | M3 | 6 | 1.8 | 20 |
| E863 | 20 | 6 | 13 | M3 | 11 | 3.0 | 10 |
| E864 | 25 | 7 | 15 | M4 | 22 | 4.0 | 10 |
| E865 | 32 | 7 | 15 | M4 | 32 | 8.0 | 5 |
| E866 | 36 | 8 | 15 | M4 | 45 | 10.0 | 5 |
| E867 | 40 | 8 | 18 | M5 | 60 | 12.5 | 5 |
| E868 | 47 | 9 | 17 | M4 | 90 | 18.0 | 1 |
| E869 | 50 | 10 | 22 | M6 | 110 | 22.0 | 1 |
| E870 | 57 | 10.5 | 18.5 | M4 | 145 | 28.0 | 1 |
| E871 | 63 | 14 | 30 | M8 | 240 | 35.0 | 1 |
| E872 | 80 | 18 | 34 | M10 | 520 | 60.0 | 1 |
| E873 | 90 | 20 | 40 | M10 | 820 | 70.0 | 1 |
| E874 | 100 | 22 | 42 | M12 | 940 | 90.0 | 1 |
| E875 | 125 | 26 | 50 | M14 | 1720 | 130.0 | 1 |
